6EDL04I06PTXUMA1 Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 28-SOIC (0.295, 7.50mm Width)
- Description: IC GATE DRVR HALF-BRIDGE DSO28
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
6EDL04I06PTXUMA1 Specifications:
- MfrPart.: 6EDL04I06PTXUMA1
- Mfr: Infineon Technologies
- Description: IC GATE DRVR HALF-BRIDGE DSO28
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: EiceDriver™
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: 3-Phase
- NumberofDrivers: 6
- GateType: IGBT, N-Channel, P-Channel MOSFET
- Voltage-Supply: 13V ~ 17.5V
- LogicVoltage-VILVIH: 1.1V, 1.7V
- Current-PeakOutput(SourceSink): -
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 600 V
- Rise/FallTime(Typ): 60ns, 26ns
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 28-SOIC (0.295, 7.50mm Width)
- 6EDL04I06PTXUMA1 Infineon, IC GATE DRVR HALF-BRIDGE DSO28, Integrated Circuits (ICs)~PMIC - Gate Drivers
6EDL04I06PTXUMA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
