BSB056N10NN3GXUMA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: MG-WDSON-2, CanPAK M™
- Description: MOSFET N-CH 100V 9A/83A 2WDSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BSB056N10NN3GXUMA1 Specifications:
- MfrPart.: BSB056N10NN3GXUMA1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 100V 9A/83A 2WDSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: OptiMOS™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta), 83A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 5.6mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 3.5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 74 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5500 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 2.8W (Ta), 78W (Tc)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: MG-WDSON-2, CanPAK M™
- BSB056N10NN3GXUMA1 Infineon, MOSFET N-CH 100V 9A/83A 2WDSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
