IGZ75N65H5XKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: IGZ75N65 - DISCRETE IGBT WITHOUT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IGZ75N65H5XKSA1 Specifications:
- MfrPart.: IGZ75N65H5XKSA1
- Mfr: Infineon Technologies
- Description: IGZ75N65 - DISCRETE IGBT WITHOUT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: TrenchStop™ 5
- PartStatus: Active
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 119 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 395 W
- SwitchingEnergy: 680µJ (on), 430µJ (off)
- InputType: Standard
- GateCharge: 166 nC
- Td(on/off)@25°C: 26ns/347ns
- TestCondition: 400V, 37.5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- IGZ75N65H5XKSA1 Infineon, IGZ75N65 - DISCRETE IGBT WITHOUT, Discrete Semiconductor Products~Transistors - IGBTs - Single
