IKQ75N120CH3XKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 150A TO247-3-46
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IKQ75N120CH3XKSA1 Specifications:
- MfrPart.: IKQ75N120CH3XKSA1
- Mfr: Infineon Technologies
- Description: IGBT 1200V 150A TO247-3-46
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.35V @ 15V, 75A
- Power-Max: 938 W
- SwitchingEnergy: 6.4mJ (on), 2.8mJ (off)
- InputType: Standard
- GateCharge: 370 nC
- Td(on/off)@25°C: 34ns/282ns
- TestCondition: 600V, 75A, 6Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- IKQ75N120CH3XKSA1 Infineon, IGBT 1200V 150A TO247-3-46, Discrete Semiconductor Products~Transistors - IGBTs - Single
IKQ75N120CH3XKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
