IR53HD420-P2 Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 9-SIP, 7 Leads
- Description: IC HALF BRIDGE SELF-OSC 9-SIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IR53HD420-P2 Specifications:
- MfrPart.: IR53HD420-P2
- Mfr: Infineon Technologies
- Description: IC HALF BRIDGE SELF-OSC 9-SIP
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge
- Applications: AC Motors
- Interface: On/Off
- LoadType: Inductive
- Technology: Power MOSFET
- RdsOn(Typ): 3Ohm
- Current-Output/Channel: 850mA
- Current-PeakOutput: -
- Voltage-Supply: 10V ~ 15.6V
- Voltage-Load: 500V (Max)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- Features: Bootstrap Circuit, Internal Oscillator
- FaultProtection: UVLO
- MountingType: Through Hole
- Package/Case: 9-SIP, 7 Leads
- IR53HD420-P2 Infineon, IC HALF BRIDGE SELF-OSC 9-SIP, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
