IRFB7746PBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 75V 59A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRFB7746PBF Specifications:
- MfrPart.: IRFB7746PBF
- Mfr: International Rectifier (Now part of Infineon Technologies)
- Description: MOSFET N-CH 75V 59A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: StrongIRFET™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 75 V
- Current-ContinuousDrain(Id)@25°C: 59A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 10.6mOhm @ 35A, 10V
- Vgs(th)(Max)@Id: 3.7V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 83 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3.049 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 99W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- IRFB7746PBF Infineon, MOSFET N-CH 75V 59A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRFB7746PBF, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
