IRGS4056DPBF Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT WITH RECOVERY DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRGS4056DPBF Specifications:
- MfrPart.: IRGS4056DPBF
- Mfr: Infineon Technologies
- Description: IGBT WITH RECOVERY DIODE
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 24 A
- Current-CollectorPulsed(Icm): 48 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 12A
- Power-Max: 140 W
- SwitchingEnergy: 75µJ (on), 225µJ (off)
- InputType: Standard
- GateCharge: 25 nC
- Td(on/off)@25°C: 31ns/83ns
- TestCondition: 400V, 12A, 22Ohm, 15V
- ReverseRecoveryTime(trr): 68 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- IRGS4056DPBF Infineon, IGBT WITH RECOVERY DIODE, Discrete Semiconductor Products~Transistors - IGBTs - Single
