IRL3803S Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 30V 140A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRL3803S Specifications:
- MfrPart.: IRL3803S
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 140A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: HEXFET®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 140A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6mOhm @ 71A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 140 nC @ 4.5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 5000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.8W (Ta), 200W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- IRL3803S Infineon, MOSFET N-CH 30V 140A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRL3803S, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
