IRS2186PBF Images
- Manufacturer: Infineon Technologies
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRS2186PBF Specifications:
- MfrPart.: IRS2186PBF
- Mfr: Infineon Technologies
- Description: IC GATE DRV HI-SIDE/LO-SIDE 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- DrivenConfiguration: High-Side or Low-Side
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT, N-Channel MOSFET
- Voltage-Supply: 10V ~ 20V
- LogicVoltage-VILVIH: 0.8V, 2.5V
- Current-PeakOutput(SourceSink): 4A, 4A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): 600 V
- Rise/FallTime(Typ): 22ns, 18ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- IRS2186PBF Infineon, IC GATE DRV HI-SIDE/LO-SIDE 8DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
