SGP20N60 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT, 40A, 600V, N-CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGP20N60 Specifications:
- MfrPart.: SGP20N60
- Mfr: Infineon Technologies
- Description: IGBT, 40A, 600V, N-CHANNEL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 20A
- Power-Max: 179 W
- SwitchingEnergy: 440µJ (on), 330µJ (off)
- InputType: Standard
- GateCharge: 100 nC
- Td(on/off)@25°C: 36ns/225ns
- TestCondition: 400V, 20A, 16Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- SGP20N60 Infineon, IGBT, 40A, 600V, N-CHANNEL, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGP20N60, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
