IKY40N120CS6XKSA1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: IGBT TRENCH/FS 1200V 80A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IKY40N120CS6XKSA1 Specifications:
- MfrPart.: IKY40N120CS6XKSA1
- Mfr: Infineon Technologies
- Description: IGBT TRENCH/FS 1200V 80A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: TrenchStop™
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.15V @ 15V, 40A
- Power-Max: 500 W
- SwitchingEnergy: 1.45mJ (on), 1.55mJ (off)
- InputType: Standard
- GateCharge: 285 nC
- Td(on/off)@25°C: 27ns/315ns
- TestCondition: 600V, 40A, 9Ohm, 15V
- ReverseRecoveryTime(trr): 255 ns
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- IKY40N120CS6XKSA1 Infineon, IGBT TRENCH/FS 1200V 80A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
IKY40N120CS6XKSA1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
