IRF7523D1 Images
- Manufacturer: Infineon Technologies
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Micro8™
- Description: MOSFET N-CH 30V 2.7A MICRO8
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRF7523D1 Specifications:
- MfrPart.: IRF7523D1
- Mfr: Infineon Technologies
- Description: MOSFET N-CH 30V 2.7A MICRO8
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: FETKY™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 2.7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 130mOhm @ 1.7A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 12 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 210 pF @ 25 V
- FETFeature: Schottky Diode (Isolated)
- PowerDissipation(Max): 1.25W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: Micro8™
- IRF7523D1 Infineon, MOSFET N-CH 30V 2.7A MICRO8, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
IRF7523D1, Infineon authentic parts in stock from Infineon authorized distributors, order today, can ship immediately.
